AutoCAD Electrical 2018 Fundamentals with NFPA Standards: Autodesk Authorized Publisher

AutoCAD Electrical 2018 Fundamentals with NFPA Standards: Autodesk Authorized Publisher

ISBN-13: 9781946571366
Regular price $90.62
Regular price $94.74 Sale price $90.62
Sale Sold out
The AutoCAD(R) Electrical 2018: Fundamentals with NFPA Standards learning guide covers the indispensable core topics for working with the AutoCAD(R) Electrical software. In this learning guide, you will learn how to use many of the powerful electrical drawing creation tools in the AutoCAD Electrical software. You will create schematic drawings (ladder logic and point to point), panel drawings, and PLC-I/O circuits using automated commands for symbol insertion, component tagging, wire numbering, and drawing modification. In addition, you are introduced to methods of customizing AutoCAD Electrical symbols, circuits, and databases. Other topics covered include titleblock linking, reporting tools, templates, and project files. Topics Covered Understanding project files Creating and editing schematic and panel drawings Working with PLC symbols Creating custom symbols Generating reports Prerequisites Before taking this course, students need to have a good working knowledge of the AutoCAD(R) software and electrical terminology.

  • | Author: ASCENT - Center for Technical Knowledge
  • | Publisher: ASCENT, Center for Technical Knowledge
  • | Publication Date: Jul 28, 2017
  • | Number of Pages: 672 pages
  • | Language: English
  • | Binding: Paperback
  • | ISBN-10: 1946571369
  • | ISBN-13: 9781946571366
